MAIN
- Sensor 160x120px @ 17µm
- Objective Lens 6 mm
- Detection Range (Vehicle 1.4 x 4m) 559 m
- Detection Range (Human 1.8 x 0.5m) 182 m
SENSOR
- Type Vanadium Oxide Uncooled Focal Plane Arrays
- Resolution, pixels 160 x 120 px
- Pixel pitch, µm 17µm
- Frame rate, Hz 50 Hz
- NETD <35mK
OPTICS
- Objective lens F1.1
- Magnification (Optical) 0.6 x
- Magnification (Digital) 1x, 2x, 4x,
- Field of view 24.7° × 18.7° (H × V)
DISPLAY
- Type 5.08mm, LCOS
- Resolution, Pixels 720 × 540
- Colour Palettes Black Hot, White Hot, Red Hot, Fusion
Video Recorder
- Video / Photo resolution
- Video / Photo format
- Build in memory, Gb 8GB
Additional features
- Hot Tracking YES
- WiFI hot spot YES
- T-Vision App support YES
Environmental
- Degree of protection, IP code IP67
- Dust protection Protected against dust ingress
- Water protection Protected against temporary submersion in water
- Operating temperature range -20 °C to 55 °C
WEIGHT & SIZE
- Dimensions, mm 158 mm x 61 mm x 57 mm
- Weight, kg 0.25 kg
POWER SUPPLY
- Operating time on battery
- (WiFi & Hot tracking disabled)” 10 Hours continuous running
- Charging interface USB-C
- Battery capacity after 1000 cycles 80%
Warranty Period
- 3 Years
SKU
- HIKVUL6
